Description :
KRFM 315 fans can be used where the air that it exhausts has particles in it that would damage the motor. Capable of carrying air up to max. 120 Celcius degree. Its single-phase motor and easy-to install body allows a simple use.
| MOTOR PROTECTION CLASS |
IP 44 |
| MOTOR INSULATION CLASS | F CLASS |
| MOTOR ENCLOSURE TYPE | AC MOTOR |
| BODY MATERIAL | SHEET METAL |
| BODY COATING | ELECTROSTATIC POWDER PAINT |
| IMPELLER TYPE | BACKWARD CURVED |
| IMPELLER MATERIAL | GALVANIZED SHEET METAL |
| DUTY CYCLE | IEC Duty Cycle-S1 |
| WORKING AMBIENT TEMP | -20 - +50 °C |
| STANDARDS |
IEC-60335-2-80, ISO 1940-1 |
TECHNICAL SPECIFICATIONS
| MODEL | VOLTAGE (V) | FREQUENCY (Hz) | POWER (W) | REV (RPM) | FLOW RATE (m3/h) | SOUND PRESSURE dB(A) 3m | WEIGHT (KG) |
|---|---|---|---|---|---|---|---|
| KRFM 315A | 230 | 50 | 400 | 2750 | 1960 | 56 | 11,5 |
| KRFM 315B | 230 | 50 | 400 | 1400 | 1650 | 48 | 11,5 |
